AIR-CAP3602I-EK910

AIR-CAP3602I-EK910 Specification

Product Description

Cisco Catalyst 3600 Series Access Points with integrated antennas

Devide Type

Wireless  Access point

Regulatory domain

A regulatory domain

Supported wireless LAN controllers

● Cisco 2500 Series Wireless Controllers
● Cisco Wireless Controller Module for ISR G2
● Cisco Wireless Services Module 2 (WiSM2) for Catalyst 6500 Series Switches
● Cisco 5500 Series Wireless Controllers

Software

Cisco Unified Wireless Network Software Release with AireOS Wireless Controllers:
● 7.2 or later for the Cisco Aironet 3600 Series Access Point
● 7.4 or later for support of the Wireless Security Module for the 3600 Series Access Point
● 7.5 or later for support of the 802.11ac Wave 1 Module for the 3600 Series Access Point

Data rates supported

● 802.11a: up to 54 Mbps
● 802.11g: up to 54 Mbps

Antenna (integrated)

●  2.4 GHz, gain 4 dBi, internal omni, horizontal beamwidth 360°

Interfaces

●  10/100/1000BASE-T autosensing (RJ-45)

System memory

●  256 MB DRAM

Module options

● Cisco Aironet Wireless Security Module
● Cisco Aironet IEEE 802.1ac Wave 1 Module

Power consumption (purchase separately)

● No external module installed, 4×4:3 on 2.4/5 GHz : 16.1 Watts

● No external module installed, 3×3:3 on 2.4/5 GHz : 15.4 Watts

IEEE standards

● IEEE 802.11a/b/g, 802.11n, 802.11h, 802.11d

Security

● 802.11i, Wi-Fi Protected Access 2 (WPA2), WPA
● 802.1X

Extensible Authentication Protocol (EAP) types

● EAP-Transport Layer Security (TLS)
● EAP-Tunneled TLS (TTLS) or Microsoft Challenge Handshake Authentication Protocol Version 2 (MSCHAPv2)
● Protected EAP (PEAP) v0 or EAP-MSCHAPv2

Integrated Antenna

●  5 GHz, Gain 4 dBi, internal omni, horizontal beamwidth 360°

External Antenna (Sold Separately)

●  Cisco offers the industry’s broadest selection of802.11n antennas delivering optimal coverage for a variety of deployment scenarios

Indicators

Dimensions
(W x L x H)

Weight

Environmental

Cisco Aironet 3600i

●  Nonoperating (storage) temperature: -22 to 158°F (-30 to 70°C)

●  Nonoperating (storage) Altitude Test -25˚C, 15,000 ft.

●  Operating temperature: 32 to 104°F (0 to 40°C)

●  Operating humidity: 10 to 90% percent (noncondensing)

●  Operating Altitude Test -40˚C, 9843 ft.

Cisco Aironet 3600e

●  Nonoperating (storage) temperature: -22 to 158°F (-30 to 70°C)

●  Nonoperating (storage) Altitude Test – 25˚C, 15,000 ft.

●  Operating temperature: -4 to 131°F (-20 to 55°C)

●  Operating humidity: 10 to 90 percent (noncondensing)

●  Operating Altitude Test -40˚C, 9843 ft.
