AIR-AP1131AG-J-K9 Datasheet

AIR-AP1131AG-J-K9 Datasheet Specification

• 802.11g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps

• 2.412 to 2.462 GHz; 11 channels

• 5.15 to 5.35, 5.725 to 5.825 GHz; 12 channels

China

• 2.412 to 2.472 GHz; 13 channels

• 5.725 to 5.825 GHz; 4 channels

ETSI

• 2.412 to 2.472 GHz; 13 channels

• 5.15 to 5.725 GHz; 19 channels

Israel

• 2.432 to 2.472 GHz; 9 channels

• 5.15 to 5.35 GHz, 8 channels

Japan (TELEC)

• 2.412 to 2.472 GHz; 13 channels Orthogonal Frequency Division Multiplexing (OFDM)

• 2.412 to 2.484 GHz; 14 channels Complementary Code Keying (CCK)

• 5.15 to 5.25 GHz; 4 channels

Japan-P (TELEC 2 (Japan2) Cnfg)

• 2.412 to 2.472 GHz; 13 channels Orthogonal Frequency Division Multiplexing (OFDM)

• 2.412 to 2.484 GHz; 14 channels Complementary Code Keying (CCK)

• 5.15 to 5.35 GHz, 8 channels

Japan-Q

• 2.412 to 2.472 GHz; 13 channels Orthogonal Frequency Division Multiplexing (OFDM)

• 2.412 to 2.484 GHz; 14 channels Complementary Code Keying (CCK)

• 5.15 to 5.35 GHz, 8 channels

• 5.470 to 5.725 GHz, 11 channels

Korea

• 2.412 to 2.472 GHz; 13 channels

• 5.15 to 5.35, 5.46 to 5.72, 5.725 to 5.825, 19 channels

North America

• 2.412 to 2.462 GHz; 11 channels

• 5.15 to 5.35, 5.725 to 5.825 GHz; 12 channels

Singapore

• 2.412 to 2.472 GHz, 13 channels

• 5.15 to 5.35 GHz, 8 channels and 5.725 to 5.825 GHz, 12 channels

Taiwan

• 2.412 to 2.462 GHz, 11 channels

• 5.25-5.35 GHz, 5.725 to 5.825, 7 channels

6 Mbps: -87 dBm

9 Mbps: -86 dBm

12 Mbps: -85 dBm

18 Mbps: -84 dBm

24 Mbps: -80 dBm

36 Mbps: -78 dBm

48 Mbps: -73 dBm

54 Mbps: -71 dBm

1 Mbps: -93 dBm

2 Mbps: -91 dBm

5.5 Mbps: -88 dBm

6 Mbps: -86 dBm

9 Mbps: -85 dBm

11 Mbps: -85 dBm

12 Mbps: -84 dBm

18 Mbps: -83 dBm

24 Mbps: -79 dBm

36 Mbps: -77 dBm

48 Mbps: -72 dBm

54 Mbps: -70 dBm

OFDM:

17 dBm (50 mW)

15 dBm (30 mW)

14 dBm (25 mW)

11 dBm (12 mW)

8 dBm (6 mW)

5 dBm (3 mW)

2 mW (2 dBm)

-1 dBm (1 mW)

CCK:

20 dBm (100 mW)

17 dBm (50 mW)

14 dBm (25 mW)

11 dBm (12 mW)

8 dBm (6 mW)

5 dBm (3 mW)

2 dBm (2 mW)

-1 dBm (1 mW)

OFDM:

17 dBm (50 mW)

14 dBm (25 mW)

11 dBm (12 mW)

8 dBm (6 mW)

5 dBm (3 mW)

2 dBm (2 mW)

-1 dBm (1 mW)

80 ft (24 m) @ 54 Mbps

150 ft (45 m) @ 48 Mbps

200 ft (60 m) @ 36 Mbps

225 ft (69 m) @ 24 Mbps

250 ft (76 m) @ 18 Mbps

275 ft (84 m) @ 12 Mbps

300 ft (91 m) @ 9 Mbps

325 ft (100 m) @ 6 Mbps

100 ft (30 m) @ 54 Mbps

175 ft (53 m) @ 48 Mbps

250 ft (76 m) @ 36 Mbps

275 ft (84 m) @ 24 Mbps

325 ft (100 m) @ 18 Mbps

350 ft (107 m) @ 12 Mbps

360 ft (110 m) @ 11 Mbps

375 ft (114 m) @ 9 Mbps

400 ft (122 m) @ 6 Mbps

420 ft (128 m) @ 5.5 Mbps

440 ft (134 m) @ 2 Mbps

450 ft (137 m) @ 1 Mbps

100 ft (30 m) @ 54 Mbps

300 ft (91 m) @ 48 Mbps

425 ft (130 m) @ 36 Mbps

500 ft (152 m) @ 24 Mbps

550 ft (168 m) @ 18 Mbps

600 ft (183 m) @ 12 Mbps

625 ft (190 m) @ 9 Mbps

650 ft (198 m) @ 6 Mbps

120 ft (37 m) @ 54 Mbps

350 ft (107 m) @ 48 Mbps

550 ft (168 m) @ 36 Mbps

650 ft (198 m) @ 24 Mbps

750 ft (229 m) @ 18 Mbps

800 ft (244 m) @ 12 Mbps

820 ft (250 m) @ 11 Mbps

875 ft (267 m) @ 9 Mbps

900 ft (274 m) @ 6 Mbps

910 ft (277 m) @ 5.5 Mbps

940 ft (287 m) @ 2 Mbps

950 ft (290 m) @ 1 Mbps

Safety

• UL 60950-1

• CAN/CSA-C22.2 No. 60950-1

• UL 2043

• IEC 60950-1

• EN 60950-1

• NIST FIPS 140-2 level 2 validation

Radio Approvals

• FCC Part 15.247, 15.407

• RSS-210 (Canada)

• EN 300.328, EN 301.893 (Europe)

• ARIB-STD 33 (Japan)

• ARIB-STD 66 (Japan)

• ARIB-STD T71 (Japan)

• AS/NZS 4268.2003 (Australia and New Zealand)

EMI and Susceptibility (Class B)

• FCC Part 15.107 and 15.109

• ICES-003 (Canada)

• VCCI (Japan)

• EN 301.489-1 and -17 (Europe)

Security

• 802.11i, WPA2, WPA

• 802.1X

• AES, TKIP

• FIPS 140-2 Pre-Validation List

• Common Criteria (when running Cisco IOS software)

Other

• IEEE 802.11g and IEEE 802.11a

• FCC Bulletin OET-65C

• RSS-102

• Gain 3.0 dBi

• Horizontal Beamwidth 360°

• 5 GHz

• Gain 4.5 dBi

• Horizontal Beamwidth 360°

Security Standards

• WPA

• WPA2 (802.11i)

• Cisco TKIP

• Cisco message integrity check (MIC)

• IEEE 802.11 WEP keys of 40 bits and 128 bits

802.1X EAP types:

• EAP-Flexible Authentication via Secure Tunneling (EAP-FAST)

• Protected EAP-Generic Token Card (PEAP-GTC)

• PEAP-Microsoft Challenge Authentication Protocol Version 2 (PEAP-MSCHAP)

• EAP-Transport Layer Security (EAP-TLS)

• EAP-Tunneled TLS (EAP-TTLS)

• EAP-Subscriber Identity Module (EAP-SIM)

• Cisco LEAP

Encryption

• AES-CCMP encryption (WPA2)

• TKIP (WPA)

• Cisco TKIP

• WPA TKIP

• IEEE 802.11 WEP keys of 40 bits and 128 bits

• Status LED indicates operating state, association status, error/warning condition, boot sequence, and maintenance status

Internal:

• Ethernet LED indicates activity over the Ethernet, status

• Radio LED indicates activity over the radios, status

• Altitude: 0 to 2500m

• 32 to 104°F (0 to 40°C)

• 10 to 90% humidity (noncondensing)

Non Operating

• -40 to 158F (-40 to 70C)

• Up to 95% humidity (noncondensing)

• 16 MB FLASH

• 36-57 VDC (device)
