| Microphone capacity |
Wireless microphone≤300 |
| Frequency response |
20Hz ~ 20KHz |
| SNR |
>85dB(A) |
| Dynamic range |
>80dB(A) |
| THD |
<0.05% |
| Main power |
100-240AC/50-60Hz |
| Audio output |
LINE OUT 1: 1Vrms XLR balanced output; LINE OUT 2: 1Vrms lotus unbalanced output |
| Audio input |
LINE IN 1: 775mVrms XLR balanced input; LINE IN 2: 775mVrms lotus unbalanced input |
| EXTENSION port |
1 channel, connected to conference system expansion equipment |
| WIFI network port |
2 for connect to wireless AP |
| PC network port |
1 for connect to the computer |
| RS-232 interface |
2 channels, 1 channel for camera tracking, 1 channel for docking external equipment |
| RS-485 interface |
1 for camera tracking |
| Balanced input impedance |
>10KΩ |
| Balanced output impedance |
470Ω |
| Unbalanced input impedance |
>5KΩ |
| Unbalanced output impedance |
470Ω |
| Static power consumption |
7.1W |
| Output power consumption |
≤30W |
| Display |
2.2-inch TFT-LCD display, resolution 240*320 pixels |
| Operate temperature |
-10℃~+60℃ |
| Working humidity |
20%~80% relative humidity, no condensation |
| Colour |
Black |
| Net weight |
3.2Kg |
| Dimension |
484×258×44mm |
| Installation method |
19-inch standard cabinet |
