| Audio Output Details |
| Speaker Type |
None |
| Card Reader |
| Type |
Card reader |
| Supported Flash Memory Cards |
microSDHC |
| Chassis |
| Form Factor |
Blade |
| Manufacturer Form Factor |
Blade |
| Hot-Swap Bays Qty |
2 |
| Server Storage Bays |
Hot-swap |
| Server Swappable Drive Interface |
SATA |
| Server Swappable Drive Form Factor |
2.5 |
| Server Swappable Drive Form Factor (metric) |
6.4 cm |
| Display |
| Type |
None. |
| Expansion Bays |
| Form Factor (metric) |
6.4 cm SFF |
| Type |
Hot-swap |
| Expansion Slots |
| Slot Comments |
X16 mode |
| Type |
PCIe 3.0 x16 |
| Hard Drive |
| Type |
No HDD |
| Hard Drive (2nd) |
| Type |
None |
| Hard Drive (3rd) |
| Type |
None |
| Hard Drive (4th) |
| Type |
None |
| Optical Storage |
| Type |
None |
| Drive Type |
No optical drive |
| RAM Supported |
| Max Size |
512 GB |
| Type |
PC4-20800 |
| Registered or Buffered |
Registered |
| Video Memory |
| Installed Size |
16 MB |
| Bay Provided |
| Form Factor |
2.5 SFF |
| Total Qty |
2 |
| Free Qty |
2 |
| Cabinet |
| Chassis Built-in Devices |
LED panel |
| Environmental Parameters |
| Min Operating Temperature |
50 °F |
| Max Operating Temperature |
95 °F |
| Humidity Range Operating |
10 – 90% (non-condensing) |
| Header |
| Compatibility |
PC |
| Manufacturer |
HP CTO Server Avnet |
| Packaged Quantity |
1 |
| Product Line |
HPE ProLiant |
| Model |
BL460c Gen10 |
| Brand |
HPE |
| Interface Provided |
| Qty |
1 |
| Location |
1 internal |
| Type |
LAN |
| Connector Type |
RJ-45 |
| Comment |
HPE iLO 5 to Onboard Administrator link |
| Mainboard |
| Chipset Type |
Intel C621 |
| Processor Socket |
Socket P |
| Miscellaneous |
| Compliant Standards |
ACPI 6.1 |
| Pricing Type |
CTO |
| Color Category |
Black |
| Networking |
| Data Link Protocol |
Gigabit Ethernet |
| Interface Type |
FlexibleLOM |
| Remote Management Controller |
Integrated Lights-Out 4 |
| Optical Storage (2nd) |
| Type |
None |
| Drive Type |
No optical drive |
| Printer |
| Type |
None |
| Processor |
| Type |
No CPU |
| Upgradability |
Upgradable |
| Service |
| Support Details Type |
Limited warranty |
| Support Details Service Included |
Parts and labor |
| Support Details Location |
On-site |
| Support Details Full Contract Period |
3 years |
| Service & Support Details |
| Response Time |
Next business day |
| Slot Provided |
| Total Qty |
2 |
| Free Qty |
2 |
| Software |
| Type |
HPE Server UEFI |
| Storage Controller |
| Type |
Serial ATA |
| Interface Type |
Serial ATA-600 |
| Channel Qty |
4 |
| Installed Qty |
1 |
| Storage Controller Name |
HPE Smart Array S100i SR Software |
| Storage Removable |
| Type |
None |
| System |
| Type |
Server |
| OS Certified |
CentOS, Citrix XenServer 7.0, Citrix XenServer 7.1, Microsoft Windows Server 2012 R2 Datacenter, Microsoft Windows Server 2012 R2 Standard, Microsoft Windows Server 2012 R2 with Hyper-V, Microsoft Windows Server 2012 with Hyper-V, Microsoft Windows Server 2016, Microsoft Windows Server 2016 with Hyper-V, Red Hat Enterprise Linux 6.9, Red Hat Enterprise Linux 7.4, SuSE Linux Enterprise Server 12 SP2, SuSE Linux Enterprise Server 12 SP3, VMware vSphere 6.5 |
| Hard Drive Capacity |
0 GB |
| Video Output |
| Graphics Processor Vendor |
Matrox G200eH |
| Graphics Processor Series |
Matrox G200 |
| Dimensions & Weight |
| Width |
2.2 in |
| Depth |
20.4 in |
| Height |
7.1 in |
| Weight |
10.47 lbs |
| RAM |
| Installed Size |
0 GB |
| Max Supported Size |
1.5 TB |
| Technology |
DDR4 SDRAM |
| Form Factor |
DIMM 288-pin |
| Memory Speed |
2400 MHz |
| Memory Specification Compliance |
PC4-20800 |
| Empty Slots |
16 |
| Slots Qty |
16 |
| Rated Memory Speed |
2666 MHz |
| Service & Support |
| Type |
3 years warranty |
| On-Site Warranty |
On-site |
