HPE 860120-S01 Specification |
| Number of processors | |
| Processor core available | - 6 or 8 or 10 or 12 or 14 or 16 or 18
|
| Processor cache | - 15MB L3
- 20MB L3
- 25MB L3
- 30MB L3
- 35MB L3
- 40MB L3
- 45MB L3
|
| Processor speed | |
| Form factor (fully configured) | |
| Form factor chassis | |
| Power supply type | |
| Expansion slots | - (6) Maximum – For detail descriptions reference the QuickSpecs
|
| Memory, maximum | |
| Memory slots | |
| Memory type | |
| Memory protection features | - Advanced ECC
- Memory Online Spare Mode
- Memory Lock Step Mode
|
| Drive description | - (4) LFF SAS/SATA or
- (10) LFF SAS/SATA or
- (8) SFF SAS/SATA or
- (16) SFF SAS/SATA
|
| System fan features | - Non-hot plug non-redundant
|
| Graphic card | |
| Network controller | - Broadcom 5717 Dual-port 1GbE 2 Ports per controller
- Broadcom 5717 Dual-port 1GbE
|
| Storage controller | - (1) Dynamic Smart Array B140i or
- (1) H240 Host Bus Adapter
- Depending on model
|
| Product dimensions (H x W x D) | 7.87 x 24.41 x 17.03 in |
| Weight | 49 lb |
| Infrastructure management | - iLO Management (standard), Intelligent Provisioning (standard), iLO Essentials (optional), iLO Scale-Out (optional), iLO Advanced (optional)
|
