| General |
| Product Type | Storage controller (RAID) |
| Service & Support |
| Type | 3 years warranty |
| Bay Provided |
| Type | None |
| Header |
| Compatibility | PC |
| Manufacturer | Hewlett-Packard |
| Packaged Quantity | 1 |
| Product Line | HPE Smart Array |
| Model | P441/4GB with FBWC |
| Brand | HPE |
| Interface Provided |
| Qty | 2 |
| Connector Type | 36 pin 4x Mini SAS HD (SFF-8643) |
| Connector Location | External |
| Type | SATA 6Gb/s / SAS 12Gb/s |
| Miscellaneous |
| Compliant Standards | WEEE |
| Power Device |
| Type | None |
| Service |
| Support Details Type | Limited warranty |
| Support Details Service Included | Parts |
| Support Details Full Contract Period | 3 years |
| Storage Controller |
| Form Factor | Plug-in card |
| Bus Type | PCI Express 3.0 x8 |
| Supported Devices | Disk array (RAID), Hard drive |
| RAID Level | RAID 0, RAID 1, RAID 1 ADM, RAID 10, RAID 10 ADM, RAID 5, RAID 50, RAID 6, RAID 60 |
| Data Transfer Rate | 1.2 GBps |
| Interface Type | SATA |
| Max Storage Devices Qty | 200 |
| Channel Qty | 8 |
| Buffer Size | 4 GB |
| Low Profile | Low profile |
| Host Bus | PCIe 3.0 x8 |
| Interface | SATA 6Gb/s / SAS 12Gb/s |
| System Requirements |
| Min Operating System | Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Red Hat Enterprise Linux 5, Red Hat Enterprise Linux 6, SuSE Linux Enterprise Server 11 for x86, SuSE Linux Enterprise Server 11 x64 Edition, VMware ESXi 5.0 update 2, VMware ESXi 5.1 update 1, VMware vSphere 5.5 |
| Dimensions & Weight |
| Width | 2.3 in |
| Depth | 9.5 in |
| Height | 7.5 in |
| Weight | 15.87 oz |
