| Bay Provided |
| Type | None |
| Header |
| Compatibility | PC |
| Manufacturer | Hewlett-Packard |
| Packaged Quantity | 1 |
| Product Line | HPE Smart Array |
| Model | P440ar/2GB with FBWC |
| Brand | HPE |
| Interface Provided |
| Qty | 2 |
| Connector Location | Internal |
| Type | SATA 6Gb/s / SAS 12Gb/s |
| Miscellaneous |
| Compliant Standards | WEEE |
| Features | Dynamic sector repair, HBA Mode, HP SmartCache |
| Power Device |
| Type | None |
| Storage Controller |
| Form Factor | Plug-in card |
| Supported Devices | Disk array (RAID) |
| RAID Level | RAID 0, RAID 1, RAID 1 ADM, RAID 10, RAID 10 ADM, RAID 5, RAID 50, RAID 6, RAID 60 |
| Data Transfer Rate | 1.2 GBps |
| Channel Qty | 26 |
| Buffer Size | 2 GB |
| Host Bus | PCIe 3.0 x8 |
| Interface | SATA 6Gb/s / SAS 12Gb/s |
| System Requirements |
| Min Operating System | Microsoft Windows Server 2008, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Oracle Solaris 11.1, Red Hat Enterprise Linux 7, SuSE Linux Enterprise Server 11 SP3, Ubuntu 12.04, Ubuntu 14.04, VMware ESXi 5, VMware ESXi 5.5, VMware vSphere 5.5 |
| Dimensions & Weight |
| Width | 1.2 in |
| Depth | 4.1 in |
| Height | 5.3 in |
| Weight | 15.87 oz |
| General |
| Product Type | Storage controller (RAID) |
