| Environmental Parameters |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 131 °F |
| Humidity Range Operating | 5 – 95% (non-condensing) |
| Header |
| Compatibility | PC, Unix |
| Manufacturer | Hewlett-Packard |
| Packaged Quantity | 1 |
| Product Line | HPE FlexFabric |
| Model | 533FLR-T |
| Brand | HPE |
| Interface Provided |
| Qty | 2 |
| Connector Type | RJ-45 |
| Type | 10GBase-T |
| Miscellaneous |
| Compliant Standards | BSMI Class A, EN 61000-3-2:2006, EN 61000-3-3:2008, EN55022 Class A, EN55024, FCC Class A certified, ICES-003 Class A, RoHS 6/6, UL, VCCI Class A ITE, WEEE |
| Networking |
| Type | Network adapter |
| Form Factor | Plug-in card |
| Connectivity Technology | Wired |
| Data Transfer Rate | 10 Gbps |
| Data Link Protocol | 10 Gigabit Ethernet, Gigabit Ethernet |
| Compliant Standards | IEEE 802.1AX, IEEE 802.1Qau, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1Qbg, IEEE 802.2x, IEEE 802.3, IEEE 802.3ad (LACP), IEEE 802.3x |
| Status Indicators | Link/activity, Port status |
| Cabling Type | Ethernet 10GBase-T |
| Ports Qty | 2 |
| Features | Auto-negotiation, Jumbo Frames support, Large Send Offload (LSO), PXE support, Receive Side Scaling (RSS), TCP Segmentation Offload (TSO) |
| Interface Type | PCI Express 2.0 x8 |
| PCI Specification Revision | PCIe 2.0 |
| Ports |
| Qty | 2 |
| Type | 10Gb Ethernet |
| Processor |
| Type | BCM57810S |
| Installed Qty | 1 |
| Manufacturer | Broadcom |
| RAM |
| Installed Size | 256 MB |
| Service |
| Support Details Type | Limited warranty |
| Support Details Full Contract Period | 1 year |
| Service & Support |
| Type | 1 year warranty |
| System Requirements |
| Min Operating System | Citrix XenServer 6.0, Citrix XenServer 6.1, Microsoft Windows HPC Server 2008, Microsoft Windows MultiPoint Server 2011, Microsoft Windows Server 2008, Microsoft Windows Server 2012, Microsoft Windows Small Business Server 2011 Essentials, Microsoft Windows Small Business Server 2011 Standard, Oracle Solaris 10, Red Hat Enterprise Linux 5.7, Red Hat Enterprise Linux 5.8, Red Hat Enterprise Linux 5.9, Red Hat Enterprise Linux 6.1, Red Hat Enterprise Linux 6.2, Red Hat Enterprise Linux 6.3, SuSE Linux Enterprise Server 10 for x86/AMD64/Intel EM64T, SuSE Linux Enterprise Server 11 for x86/AMD64/Intel EM64T, VMware vSphere 4.1, VMware vSphere 5.0 |
