700751-B21
$195.00
| Model: | 700751-B21 – Networking Adapters for HPE Server |
| Detail: | HPE FlexFabric 10Gb 2P 534FLR-SFP+ Adptr |
WhatsApp Us
- Description
Description
700751-B21 Specification | |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 131 °F |
| Humidity Range Operating | 5 – 95% (non-condensing) |
| Header | |
| Compatibility | PC, Unix |
| Manufacturer | Hewlett-Packard |
| Packaged Quantity | 1 |
| Product Line | HPE FlexFabric |
| Model | 534FLR-SFP+ |
| Brand | HPE |
| Interface Provided | |
| Qty | 2 |
| Connector Type | SFP+ |
| Type | 10Gb Ethernet |
| Miscellaneous | |
| Compliant Standards | BSMI Class A, EN 61000-3-2:2006, EN 61000-3-3:2008, EN55022 Class A, EN55024, FCC Class A certified, ICES-003 Class A, RoHS 6/6, UL, VCCI Class A ITE, WEEE |
| Networking | |
| Type | Network adapter |
| Form Factor | Plug-in card |
| Connectivity Technology | Wired |
| Data Transfer Rate | 10 Gbps |
| Data Link Protocol | 10 Gigabit Ethernet |
| Compliant Standards | IEEE 802.1AX, IEEE 802.1Qau, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1Qbg, IEEE 802.2x, IEEE 802.3, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3x |
| Status Indicators | Link/activity, Port status |
| Features | Auto-negotiation, Jumbo Frames support, Large Send Offload (LSO), PXE support, Receive Side Scaling (RSS), TCP Segmentation Offload (TSO) |
| Interface Type | PCI Express 2.0 x8 |
| PCI Specification Revision | PCIe 2.0 |
| Ports | |
| Qty | 2 |
| Type | 10 Gigabit SFP+ |
| Processor | |
| Type | BCM57810S |
| Installed Qty | 1 |
| Manufacturer | Broadcom |
| RAM | |
| Installed Size | 256 MB |
| Service | |
| Support Details Type | Limited warranty |
| Support Details Full Contract Period | 1 year |
| Service & Support | |
| Type | 1 year warranty |
| System Requirements | |
| Min Operating System | Microsoft Windows HPC Server 2008, Microsoft Windows Server 2008, Oracle Solaris 10, Red Hat Enterprise Linux 5.7, Red Hat Enterprise Linux 6.1, SuSE Linux Enterprise Server 10, SuSE Linux Enterprise Server 11, VMware ESX 4.1 update 2, VMware ESXi 5.0 update 1 |
