| General |
| Product Type | Storage controller (RAID) |
| Bay Provided |
| Type | None |
| Header |
| Compatibility | PC |
| Manufacturer | Hewlett-Packard |
| Packaged Quantity | 1 |
| Product Line | HPE Smart Array |
| Model | P431/4GB with FBWC |
| Brand | HPE |
| Interface Provided |
| Qty | 2 |
| Connector Location | Internal |
| Type | SATA 6Gb/s / SAS 12Gb/s |
| Miscellaneous |
| Compliant Standards | REACH, WEEE |
| Color Category | Silver |
| Power Device |
| Type | None |
| Storage Controller |
| Form Factor | Plug-in card |
| Supported Devices | Disk array (RAID) |
| RAID Level | RAID 0, RAID 1, RAID 1 ADM, RAID 10, RAID 10 ADM, RAID 5, RAID 50, RAID 6, RAID 60 |
| Data Transfer Rate | 1.2 GBps |
| Channel Qty | 8 |
| Buffer Size | 4 GB |
| Low Profile | Low profile |
| Host Bus | PCIe 3.0 x8 |
| Interface | SATA 6Gb/s / SAS 12Gb/s |
| System Requirements |
| Min Operating System | Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Red Hat Enterprise Linux 5, Red Hat Enterprise Linux 6, SuSE Linux Enterprise Server 11, VMware ESXi 5.0 update 2, VMware ESXi 5.1 update 1, VMware vSphere 5.5 |
| Dimensions & Weight |
| Width | 2.3 in |
| Depth | 9.5 in |
| Height | 7.5 in |
| Weight | 15.87 oz |
