| Ports |
| Qty |
4 |
| Type |
10/100/1000 |
| Environmental Parameters |
| Min Operating Temperature |
32 °F |
| Max Operating Temperature |
131 °F |
| Humidity Range Operating |
10 – 90% (non-condensing) |
| Header |
| Compatibility |
PC |
| Manufacturer |
Hewlett-Packard |
| Packaged Quantity |
1 |
| Product Line |
HPE |
| Model |
331T |
| Brand |
HPE |
| Interface Provided |
| Type |
1000Base-T |
| Interface |
Ethernet 10Base-T/100Base-TX/1000Base-T |
| Qty |
4 |
| Connector Type |
RJ-45 |
| Interface Required |
| Type |
None |
| Miscellaneous |
| Compliant Standards |
EN 61000-3-2, EN 61000-3-3, EN55022, FCC Part 15 B, RoHS 6/6, VCCI Class B ITE, WEEE |
| Included Accessories |
Full-height bracket, Low-profile bracket |
| Networking |
| Type |
Network adapter |
| Form Factor |
Plug-in card |
| Connectivity Technology |
Wired |
| Data Transfer Rate |
1 Gbps |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
| Compliant Standards |
IEEE 802.1as, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Status Indicators |
Link/activity, Port transmission speed |
| Cabling Type |
Ethernet 1000Base-T, Ethernet 100Base-TX, Ethernet 10Base-T |
| Ports Qty |
4 |
| Features |
Jumbo Frames support, Large Send Offload (LSO), PXE support |
| Interface Type |
PCI Express 2.0 x4 |
| PCI Specification Revision |
PCIe 2.0 |
| Low Profile |
Low profile |
| Power Device |
| Type |
None |
| Processor |
| Type |
BCM5719 |
| Installed Qty |
1 |
| Manufacturer |
Broadcom |
| Slot Required |
| Type |
PCI Express 2.0 x4 |
| Total Qty |
1 |
| Dimensions & Weight |
| Depth |
5.2 in |
| Height |
2.7 in |
