Product Details
QSFP-100G-CU3M
AED373.00
| Model: | QSFP-100G-CU3M – Cisco 100 Gigabit Optical Modules |
| Detail: | 100GBASE-CR4 Passive Copper Cable, 3m |
Description
QSFP-100G-CU3M Specification |
|
|
Description |
Cisco 100GBASE-CR4 QSFP Passive Copper Cable, 3-meter |
|
Dimensions |
13.5 x 18.4 x 72.4 mm |
|
QSFP Port cabling specifications |
|
|
Nominal Wavelength (nm) |
|
|
Cable Type |
Direct-attach copper cable assembly |
|
Core Size (Microns) |
|
|
Modal Bandwidth (MHz*km)*1 |
|
|
Cable Distance |
3m |
|
Power Consumption (W) |
1.5 |
|
Pull Tab Color |
Orange |
|
*1 Specified at transmission wavelength. For QSFP-40/100-SRBD, Modal Bandwidth is specified at 850nm |
|
|
Environmental Conditions and Power Requirements |
|
|
Commercial temperature |
0 to 70°C (32 to 158°F) |
|
Storage temperature |
-40 to 85°C (-40 to 185°F) |
|
Regulatory and Standards compliance |
|
|
Standards |
•SFF-8665: QSFP+ 28 Gb/s 4X Pluggable Transceiver Solution (QSFP28) – Rev 1.8 May 10, 2013 •SFF-8636: Common Management Interface – DRAFT Rev 1.9 May 12, 2014 •802.3™-2012 IEEE Standard for Ethernet •IEEE 802.3ba Amendment of IEEE Std 802.3-2012 •IEEE 802.3bm Amendment of IEEE Std 802.3-2012 (D3.1, 1st August 2014) •GR-20-CORE: Generic Requirements for Optical Fiber and Optical Fiber Cable •GR-326-CORE: Generic Requirements for Single-Mode Optical Connectors and Jumper Assemblies •GR-468-CORE: Generic Requirements for Optoelectronic Devices Used in Telecommunications Equipment •GR-1435-CORE: Generic Requirements for Multifiber Optical Connectors •RoHS 6 |
|
Safety |
•Cable jacket of QSFP copper modules is UL E116441 Compliant •QSFP copper cables are ELV compliant |
