Product Details
CR5P5KBTBA61
AED154,000.00
| Model: | Huawei NetEngine5000E Cluster Router CR5P5KBTBA61 |
| Detail: | NetEngine5000E-X16A 100G (BTB) Basic Configuration AC |
Description
| CR5P5KBTBA61 Specification | |
| Throughput capability | Non-block switch fabric, support multi Chassis
The maximum system capacity: 819Tbps/64 Chassis (400G) |
| Port capacity | 15Tbps/ single Chassis (480G) |
| Interface Types | GEã€10GEã€155M POSã€622M POSã€2.5G POSã€10G POSã€40G POSã€40GEã€100GE |
| Routing protocol | IPv4 static route, OSPF, IS-IS, BGP, PIM, MSDP, MBGP |
| IPv6 | IPv4 & IPv6 dual stack; IPv6 line speed forwarding based on hardware
IPv6 static route, BGP4+, RIPng, OSPFv3, IS-ISv6 IPv6 peer discovery, PMTU discovery, TCP6, ping IPv6, Tracert IPv6, socket IPv6, TFTP IPv6 client, IPv6 policy route , IPv6 NetStream, etc Manually configured tunnel, automatic tunnel, 6 to 4 tunnel |
| High Availability | 1:1 standby for MPU, 3+1 backup switching fabric, 8+8 backup for power supply and 2+2 back for fan
hot swappable based on state，Non-stop Forwarding (NSF) and Non-stop Routing (NSR) BFD for VRRP/BGP/OSPF/ISIS/TE LSP/LDP/ LSP/TE and PIM IGP/BGP/Multicast Fast Convergence IP/LDP/BGP/TE Fast Re-Route (FRR), BGP/ISIS Auto FRR, ETH Trunk, IP Trunk In-Service Software Upgrade (ISSU), Automatic fault diagnosis function, Hot Patching Configuration Management Bi-Direction Compatible |
